R1290I Hex - Multipurpose RAIN RFID Reader

      740.70 €
      Usually dispatched within 1 to 4 weeks. Check availability with our agents.

      The Hex is a RAIN RFID reader with integrated circular polarization antenna for short and medium distance applications. The reader is powered directly by an Ethernet cable.

      WR1290IEXAAA

      Quantity :

      Did you find this product at a better price? Contact us

      100% secure payments
      • Secured Payments
      • Delivery policy
      • Terms of Sales

      Thanks to its versatile shape, the Hex is suitable for both desktop/cash desk applications and for fixed reading points.

      In addition to the internal circular polarization antenna, the Hex is equipped with a connector for an external antenna in order to increase the reading area and a set of GPIOs that allow you to control external devices. The USB port allows you to connect USB peripherals such as barcode scanners and keyboards, transforming the Hex into a powerful and versatile identification platform.

      The reader is equipped with an easy-to-use display and a keyboard interface for configuration.

      Technical features

      • Frequency of use: 865.600÷867.600 MHz (ETSI EN 302 208 v3.1.1), 902÷928 MHz (FCC part 15)
      • RF power:
        • Programmable in 18 levels (1dB steps) from 8 dBm ERP to 25 dBm ERP (Mod. R1250IE)
        • Programmable in 18 levels (1dB steps) from 8.5 dBm ERP to 25.5 dBm ERP (Mod. R1250IU)
      • Antenna:
        • Integrated circular polarized antenna
      • Number of Channels:
        • 4 channels (compliant with ETSI EN 302208 v3.1.1)
        • 50 skip channels (FCC part 15.247 compliant)
      • Standards compliance: EPC C1 G2 / ISO18000-63
      • User interface: Green LED (on), Flashing yellow LED (RF activity), Flashing red LED (Tag read), Flashing white LED for external antenna (Tag read), buzzer, proximity sensor, OLED display
      • USB interface: USB 2.0 Hi-Speed
      • Electrical Power: 5V
      • Operating Temperature: -10°C to 55°C
      • IP rating: IP30
      • Dimension: (W)220 x (L)170 x (H)25 mm
      • Weight: ~475g

      The Tile can be supplied with ETSI or FCC version and flanged or not flanged version.

      At this link you can find all the user guides and firmware for this reader.

      CAEN RFID
      WR1290IEXAAA

      Specific References

      New
